HPTLC Cellulose
| 产品编号： | 4059185 |
| 规格： | pkg of 25 plates, plate L × W 10 cm × 10 cm, glass support |
| 包装规格： | 25 UNITS |
| 产品类别： | 进口试剂 |
| 品牌： | Supelco |
| 优惠价： | 立即咨询 |
产品性质
| material【物料】 | cellulose matrix glass support |
| Quality Level【质量水平】 | 100 |
| feature【特点】 | binder Organic Polymer fluorescent indicator: no |
| packaging【包装】 | pkg of 25 plates |
| technique(s) | thin layer chromatography (TLC): suitable |
| layer thickness【层厚度】 | 60-110 μm |
| plate L × W【板长度 × 宽度】 | 10 cm × 10 cm |
| storage temp.【储存温度】 | 2-30℃ |
基本信息
| General description【一般描述】 | 25 Glass plates 10 x 10 cm Cellulose plates are used to analyze polar substances. An organic sorbent, cellulose is perfect for separating hydrophilic substances by partition chromatography. Typical applications include the analysis of amino acids, carbohydrates, and phosphates as well as nucleic acid and nucleic acid derivatives. We offer cellulose plates in two grades: TLC for conventional and HPTLC for demanding, high-performance separations. |
| Linkage【联系】 | Replaces: 5787-5; 5787 |
| Analysis Note【分析说明】 | Layer thickness: 60 - 110 µm Deviation of layer thickness per plate: ≤ 30 µm Aminoacid test hRf-values - L-serine, amino acid test: 20 - 30 - L-threonine, amino acid test: 30 - 40 - L-alanine, amino acid test: 35 - 45 - L-methionine, amino acid test: 55 - 65 - L-phenylalanine, amino acid test: 60 - 70 - L-leucine, amino acid test: 70 - 80 Typical value determined on a plate Eluent: 1-Butanol/ acetone/ acetic acid/ water (35/35/7/23 v/v/v/v) twice developed |
